High Temperature Resistance 95% Alumina Ceramic Water Heater Spark Plug Gas Burner Spark Plug

Basic Info.

Model NO.	Gas Burner Spark Plug
Ceramics Diameter	5.6mm
Transport Package	Cartons and Pallet
Specification	Gas Oven or Customized
Trademark	LS or Customized
Origin	Yangzhou, China
HS Code	8545190000
Production Capacity	100000pieces/Day

Product Description

Ceramics Material	95% Alumina
Ceramics Length	36.3mm or Custom
Ceramics Diameter	5.6mm
Wire Material	Tin alloy with Teflon protection cover
Wire Length	750mm or Custom
Color	White
Electrode material	Ocr25Al5 Cr20Ni80
Electrode Length	Custom
Electrode Diameter	6.0mm
Product name	36.3mm ceramic length Teflon wire gas stove ignition electrode
Used for	gas stove

Combustible varieties of ceramic ignition needles: combustible gas, bio-alcohol oil, well-atomized diesel, kerosene, etc., can be reliably ignited. The ignition needle adopts titanium metal surface treatment, aluminum metal steel needle, high-temperature anti-cracking 95 ceramic material, suitable for long-term combustion above 1500 degrees and under conditions of wind wear without damage, deformation, or oxidation. The burner ignition needle has the advantages of sensitive ignition, exquisite and beautiful appearance, and the core pole is made of imported alloy, which has the advantages of stable detection, durability, strong aging resistance, high temperature resistance, corrosion resistance, and high insulation strength. It has been widely used at home and abroad Applications. This product is widely used in various pipeline gas, liquefied petroleum gas, natural gas and similar water heaters, stoves, gas ovens, etc.

The terminal is inserted on the pulse, the function is to receive the electrons emitted by the pulse.
Various quick-connect terminals provide 2.8mm x 0.8 mm or 2.8mm x 0.5mm and 4.8 mm x 0.8 mm, SM terminals, sheath, and cold press ports.

Wire material: Tin alloy with Teflon protection cover
Wire advantages: non-stickiness, heat resistance, sliding properties, moisture resistance, abrasion resistance, corrosion resistance and other characteristics. Therefore, compared with other high-temperature wires, Teflon wire has excellent thermal stability and mechanical wear resistance electrical insulation properties, resistance to strong acids andalkalis, corrosion resistance, fire resistance and non-combustibility, high oxygen index, low smoke and halogen free, no aging, easy to strip. , High strength and friction resistance

Ceramics Material: 95% Alumina
The 95% alumina is made of hot pressure casting slurry and sintered at a high temperature of 1500ºC. It has the following advantages:
1. High mechanical strength and wear resistance;
2. Strong chemical resistance to acid and alkali.
3. Good electrical insulation performance at room temperature and high temperature.
4. Small mechanical strength loss under high temperature .

Electrode material:Ocr25Al5.Cr20Ni80;Diameter:6.0mm
Iron-chromium-aluminum resistance electric heating alloy has the characteristics of high resistivity, low temperature coefficient of resistance and high operating temperature
Resistance electric heating alloy, this kind of alloy has stable structure, stable electrical and physical properties, good high temperature mechanical properties, good cold deformation plasticity, good weldability, and will not produce brittle fracture after long-term use. It is mostly used in the manufacture of household appliances and heating elements whose working temperature is below 1600ºC, with long service life.

Yangzhou Lisheng Ceramics Co., Ltd. invested 3.5 million yuan in November 2015 to rent a 2358 m2 workshop located in Shuangbao Road, Liubao Industrial Concentration Zone, Baoying County, Baoying County Liubao Industrial Zone Development Co., Ltd., and purchased a slow mixer , Hot press forming machine, environmentally friendly gas pusher furnace, high temperature pusher electric furnace and other advanced equipment, with an annual output of 6 million electronic ceramics and ceramic accessories.
Services:1. The ignition electrode are in stock, so you can buy small order quantity for try to reduce your risk and warehousing cost. And also, because they are in stock,you can receive the products very soon.2. Free samples are provided only if you cover the postage.3. You will get factory price if you order 1000 or more than 1000 pcs.4. We custom ceramics only if you provide design or samples.5. On-time delivery.6. 24 hours response. You can contact us in various ways - email, inquiry, mobile, what Sapp, trade manager, Skype.7. Various payment methods are acceptable - T/T(bank wire), Paypal, Western Union, Money Gram, Escrow and more.
1,Are you a manufacturer or a trader?
We are a manufacturer with our own factory located in Jiangsu, China's second largest economic province;
2,What is the main product of your company?
We are a company specializing in ignition electrodes and spark plugs. Our products are widely used in gas appliances. We supply domestic well-known gas appliance companies, such as Macro, Huachuang gas appliance and other companies;
3,Whether to provide sample service?
If you have a contact person in China, we can send samples to him for free;If you are
abroad, we can provide samples for free, but you have to pay the freight yourself
4,How to contact you?
We have online shop in Alibaba, the address of the shop:yzlstc en alibaba com.

5,How long does it take from order to delivery;
It depends on the quantity of your order, usually around 10 days.
6,Can you provide customized services?
Yes, we can provide customized services, you can send us drawings, and we will make your products according to your drawings.
